PI-400ICRGB-02
LED Pixel Tube · PI-400ICRGB-02
40mm LED Pixel Tube
SMD5050 LED Tube Light DMX 3D for DJ Disco Music Interactive
Individually addressable LED pixel tube for 360° pixel tube effects on stage and architecture.
- Certification
- CE · ROHS · BIS
- MOQ
- 1 piece
- Delivery
- 5–7 days
- Warranty
- 2 years
Reply within 8 hours · Free sample for qualified projects
Overview
About the 40mm LED Pixel Tube
40mm LED Pixel Tube (PI-400ICRGB-02) is an LED pixel tube built on SMD5050RGB emitters, with 168 LEDs/m. Each LED is individually addressable, so the fixture drives vertical pixel tube effects and 360° tube looks for stage and architectural rigs.
Control is over DMX512, SPI, SD Card or Remote Control, with WS2811, UCS1903 or SM16703 driver ICs. It runs on low-voltage DC24V and draws 40W/M. A 360° beam angle gives an even spread across the run.
It ships in IP20/IP65 options, covering indoor and wet / outdoor installs. Expect a rated life of 50,000hrs.
Highlighted features
- Individually addressable pixels for full pixel-mapping and video effects
- IP65-rated housing for outdoor and wet-location use
- Low-voltage DC24V operation for safe, simple installation
- 360° beam angle for even, wide coverage
- Long 50,000hrs rated lifespan
Technical parameters
- LED Type
- SMD5050RGB
- Color
- Full Color
- Driver IC
- WS2811/UCS1903/SM16703
- Control Mode
- DMX512/SPI/SD Card/Remote Control
- Pixel Pitch
- 3.5mm
- LED Quantity
- 168leds/M
- Beam Angle
- 360°
- Power
- 40W/M
- Voltage
- DC24V
- Size
- 40MM*1000MM
- IP Rating
- IP20/IP65
- Lifespan
- 50,000hrs
- Warranty
- 2 Years
Model PI-400ICRGB-02 — configurable per order. Request the full datasheet.
- Payment
- T/T
- Supply
- Large factory stock
- Origin
- Shenzhen, China
- OEM / ODM
- Welcome
Built for these venues.
OEM & ODM — built to your spec.
Driver IC selection: WS2811, UCS1903, SM16703 to match your controller ecosystem.
Control protocol: configurable for DMX512, SPI, SD Card, Remote Control.
Ingress protection: IP20, IP65 for indoor through to wet / outdoor builds.
