PI-400ICRGB-02
LED Pixel Tube · PI-10060IC-50S
Video RGB LED Pixel Tube
60 LEDs/meter Square Milk White Cover LED DMX Tube Stage Event Lighting With Cutting Unit Every 1 LED
Individually addressable full-color RGB LED pixel tube for 270° pixel tube effects on stage and architecture.
- Certification
- CE · ROHS · BIS
- MOQ
- 1 piece
- Delivery
- 5–7 days
- Warranty
- 2 years
Reply within 8 hours · Free sample for qualified projects
Overview
About the Video RGB LED Pixel Tube
RGB LED Pixel Tube (PI-10060IC-50S) is a full-color RGB LED pixel tube built on SMD 5050 emitters, with 60 LEDs/m. Each LED is individually addressable, so the fixture drives vertical pixel tube effects and 270° tube looks for stage and architectural rigs.
It draws 14W/meter. A 270° beam angle gives an even spread across the run.
An IP20/IP65 rating makes it suitable for indoor and wet-location use. It is cuttable every 1 LED and links end-to-end for longer runs.
Highlighted features
- Individually addressable pixels for full pixel-mapping and video effects
- RGB colour mixing with smooth dimming and gradients
- Cuttable and end-to-end linkable for made-to-length runs
- 270° beam angle for even, wide coverage
Technical parameters
- LED Type
- SMD 5050
- Color
- RGB
- Pixels
- 60pixels/Meter
- LED Quantity
- 60 LEDs/meter
- Beam Angle
- 270°
- Power Consumption
- 14W/meter
- Cutting Unit
- Every 1 LED
- IP Rating
- IP20/IP65
- Warranty
- 2 Years
Model PI-10060IC-50S — configurable per order. Request the full datasheet.
- Payment
- T/T
- Supply
- Large factory stock
- Origin
- Shenzhen, China
- OEM / ODM
- Welcome
Built for these venues.
OEM & ODM — built to your spec.
Cut-to-length: fixtures are built to the run length your project needs.
