PI-10048ICRGB
LED Pixel Bar · PI-10060IC-50S
Half-Round RGB LED Pixel Bar · DC24V
RGB RGBW Pixel Bar LED Programmable For Nightclub Stage Lighting
Individually addressable full-color RGB LED pixel bar for pixel-mapped stage, club and event lighting.
- Certification
- CE · ROHS · BIS
- MOQ
- 1 piece
- Delivery
- 5–7 days
- Warranty
- 2 years
Reply within 8 hours · Free sample for qualified projects
Overview
About the Half-Round RGB LED Pixel Bar · DC24V
The PI-10060IC-50S is a full-color RGB LED pixel bar with 60 LEDs/m. Each LED is individually addressable, so the fixture drives pixel-mapped wash, beam and tube effects on stage and event rigs.
Control is over DMX512 or SPI. It runs on low-voltage DC 24V and draws 18W/meter. A 270° beam angle gives an even spread across the run.
It ships in IP20/IP67 options, covering indoor and wet / outdoor installs. It is cuttable every 3 LEDs and links end-to-end for longer runs.
Highlighted features
- Individually addressable pixels for full pixel-mapping and video effects
- RGB colour mixing with smooth dimming and gradients
- IP67-rated housing for outdoor and wet-location use
- Low-voltage DC 24V operation for safe, simple installation
- Cuttable and end-to-end linkable for made-to-length runs
- 270° beam angle for even, wide coverage
Technical parameters
- Color
- RGB
- Control Mode
- DMX512/SPI
- LED Quantity
- 60 LEDs/meter
- Beam Angle
- 270°
- Power Consumption
- 18W/meter
- Voltage
- DC 24V
- Cutting Unit
- Every 3 LEDs
- IP Rating
- IP20/IP67
Model PI-10060IC-50S — configurable per order. Request the full datasheet.
- Payment
- T/T
- Supply
- Large factory stock
- Origin
- Shenzhen, China
- OEM / ODM
- Welcome
Built for these venues.
OEM & ODM — built to your spec.
Cut-to-length: fixtures are built to the run length your project needs.
Control protocol: configurable for DMX512, SPI.
Ingress protection: IP20, IP67 for indoor through to wet / outdoor builds.
