PI-400ICRGB-50
LED Pixel Tube · PI-10060ICRGB
RGB LED Pixel Tube
SPI RGB LED Linear Bar Tube Light Pixel Module for Exterior Facade Decoration DMX Controlled Illumination with White Beam Effect
Individually addressable LED pixel tube for 270° pixel tube effects on stage and architecture.
- Certification
- CE · ROHS · BIS
- MOQ
- 1 piece
- Delivery
- 5–7 days
- Warranty
- 2 years
Reply within 8 hours · Free sample for qualified projects
Overview
About the RGB LED Pixel Tube
RGB LED Pixel Tube (PI-10060ICRGB) is an LED pixel tube built on SMD 5050RGB emitters, with 60 LEDs/m. Each LED is individually addressable, so the fixture drives vertical pixel tube effects and 270° tube looks for stage and architectural rigs.
Control is over SPI or DMX. It runs on low-voltage DC12V. A 270° beam angle gives an even spread across the run.
An IP67 rating makes it suitable for outdoor and wet-location use. It is cuttable every 3 LEDs and links end-to-end for longer runs.
Highlighted features
- Individually addressable pixels for full pixel-mapping and video effects
- IP67-rated housing for outdoor and wet-location use
- Low-voltage DC12V operation for safe, simple installation
- Cuttable and end-to-end linkable for made-to-length runs
- 270° beam angle for even, wide coverage
Technical parameters
- LED Type
- SMD 5050RGB
- Control Mode
- SPI/DMX
- Pixels
- 60pixels/Meter
- LED Quantity
- 60 LEDs/meter
- Beam Angle
- 270°
- Voltage
- DC12V
- Length
- 2M/1M/0.5M
- Cutting Unit
- Every 3 LEDs
- IP Rating
- IP67
Model PI-10060ICRGB — configurable per order. Request the full datasheet.
- Payment
- T/T
- Supply
- Large factory stock
- Origin
- Shenzhen, China
- OEM / ODM
- Welcome
Built for these venues.
OEM & ODM — built to your spec.
Cut-to-length: fixtures are built to the run length your project needs.
Control protocol: configurable for SPI, DMX.
Other LED Pixel Tube models
Related pixel light lines
Questions?
Building your next pixel project?
Get a sample within 7 days — talk to a Pileds engineer about channels, optics, IP-rating, and finish for your venue. We reply within one business day.
